Our Product Range
| S. No. | Reference Specification | Description of Product | Manufacturing Range and Limiting Sizes |
|---|---|---|---|
| 1 |
IS: 694 – 2010 (1100 Volts Grade) |
Aluminium/ Copper Conductor PVC Insulated Unsheathed/Sheathed Wires, Cables,
Flexible Cords and Multi Core Flexible Cables including Flat Cables of Category 02, C1 and C2 |
|
| Fixed Wiring Cables |
Single Core up to 630 sq.mm Multi Core from 2 Core x 1 sq.mm up to 4 Core x 120 sq.mm Twin Flat Cables from 2 Core x 1 sq.mm up to 2 Core x 50 sq.mm |
||
| Copper Flexible Cords and Cable |
Single Core up to 300 sq.mm
Multi Core Flexible Cords from 2 Core x 0.5 sq.mm up to 5 Core x 4 sq.mm Multi Core Flexible Circular Cables from 2 Core x 6 sq.mm up to 4 Core x 300 sq.mm Flexible Flat Cables from 2 Core x 0.5 sq.mm up to 3 Core x 95 sq.mm Multi Core Flexible Cables from 6 Core x 0.5 sq.mm up to 25 Core x 2.5 sq.mm |
||
| 2 | IS: 1554 (Part-1)-1988 (1100 Volts Grade) |
Copper/Aluminium Conductor PVC Insulated Single/ Multi Core Unarmoured/ Armoured
and Overall PVC Sheathed Power and Control Cables of Category 01, C1 and C2 |
|
| Power Cables |
Single Core up to 1000 sq.mm
Multi Core from 2 Core x 1.5 sq.mm up to 4 Core x 400 sq.mm |
||
| Control Cables | Up to 61 Cores of 1.5/2.5 sq.mm (Copper Only) | ||
| 3 | IS: 7098 (Part-1)-1988 (1100 Volts Grade) |
Copper/Aluminium Conductor XLPE Insulated Single/ Multi Core Unarmoured/ Armoured
and Overall PVC Sheathed Power and Control Cables of Category 01, C1 and C2 |
|
| Power Cables |
Single Core up to 1000 sq.mm
Multi Core from 2 Core x 1.5 sq.mm up to 4 Core x 400 sq.mm |
||
| Control Cables | Up to 61 Cores of 1.5/2.5 sq.mm (Copper Only) | ||
| 4 | IS: 14255-1995 (1100 Volts Grade) |
Circular Aluminium Conductor XLPE Insulated cores laid-up
around Circular Aluminium Alloy Conductor |
From 1 Core x 16 + 25 up to 3 Core x 95 + 70 + 16 |
| 5 | Generally Conforming to to BS: 5308 Part-1 and 2 |
Copper Conductor PVC/LDPE Insulated Cores twisted to form a Pair,
Traid or Quad, Overall/ Individual and Overall Shielded/Screened Unarmoured/Armoured Cables for Instrumentation Purpose |
From 1 Pair x 0.25 sq.mm up to 100 Pair x 2.5 sq.mm |
| 6 | Generally Conforming to BS EN: 50618 | Tinned Flexible Copper Conductor, XLPE Insulated and ZHFR Sheathed DC Solar Cables | From 1 Core x 1.5 sq.mm up to 1 Core x 300 sq.mm |
| 7 | Tailor made Cable to suit specific customer requirements. |
